Overview
Xtreme Energy™ 218/224 Retro-Fit Hydraulic Roller Cam for Chrysler 273-360. Street Machine. 3.23-3.91 gears, stock converter in 340 & 360, mild converter in 318, 9:1 Compression.
COMP Cams Xtreme Energy retrofit camshafts are built to take advantage of the latest cam technology, to provide maximum performance. Whether your use is off-roading, towing, or street performance, there is an Xtreme Energy cam available for you. By using an aggressive lobe profile, these cams provide better throttle response and more top-end horsepower than equivalent cams from other manufacturers, while delivering increased engine vacuum.
| Manufacturer Specifications | |
|---|---|
| UPC | 036584117858 |
| Manufacturer | COMP Cams® |
| Engine Family | Chrysler 273-360 c.i. 8 Cylinder (1964-2002) |
| RPM Operating Range | 1,400-5,500 |
| Cam Type | Hydraulic Roller |
| Camshaft Series | Xtreme Energy |
| Camshaft Gear Attachment | 1-Bolt |
| Usage | Street/Performance |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Advertised Intake Duration | 268 |
| Advertised Exhaust Duration | 276 |
| Intake Duration at .050 Inch Lift | 218 |
| Exhaust Duration at .050 Inch Lift | 224 |
| Intake Valve Lift | 0.535 |
| Exhaust Valve Lift | 0.531 |
| Lobe Lift Intake | 0.357 |
| Lobe Lift Exhaust | 0.354 |
| Lobe Separation | 110 |
| Intake Centerline | 106 |
| Valve Timing Lift | 0.006 |
| Exhaust Close ATDC | -2 |
| Intake Open BTDC | 3 |
| Exhaust Open BBDC | 46 |
| Intake Close ABDC | 35 |
| Lifter Style | Hydraulic Roller |
| Make | Chrysler |
Customer Reviews
No reviews to display
Additional Information
| SKU | 86820 |
|---|---|
| Factory Comparison | Retro-fit Replacement |
| Sale Unit | Each |
